Technical Parameters

Asset Type: Add New

Parameters

Color 1: Wood Color 1 (while using default material)
Color 2: Wood Color 2 (while using default material)
Wood Finish: Wood Finish (while using default material)
Material: Wood Material used

▼ BACK
Height: Chair Back Height
Angle: Chair Back Angle
Curve: Straight / Curved parameter

▼ BACK Top
Position: Position for the top part of the chair’s back
Height: Back top height
Depth: Back top depth
Curved: Straight / Curved parameter

▼ BACK Bottom
Switch: Hide/Show the bottom part of the chair’s back
Bars: Amount of vertical bars
Position: Position for the bottom part of the chair’s back
Height: Back bottom height
Curved: Straight / Curved parameter

▼ SEAT
Length: Seat length
Width: Seat width
Front Scale: Scales the front part of the seat
Back Trim: Trims the back part of the seat
Thickness: Seat thickness
Cover Sides: adds “Wood Tape” to cover the sides of the seat

▼ CUSHION
Cushion: Hides/Shows the cushion
Height Multiplier: Increase/decrease cushion height
Back Spacing: Space from the back of the seat
Material: Material used on the cushion

▼ LEGS
Position: Legs position (from the border of the chair seat)
Height: Legs height
Thickness: Legs thickness
Resolution: Back legs + chair’s back mesh density (to help when using a curved back)

▼ SIDES
Height: Sides height
Thickness: Sides thickness
Realize Instances: Activate this Only before applying the modifier to convert instances to mesh. (It may take some processing time)
