Technical Parameters

Asset Type: Add New

Parameters

Steps Material: Material Used for the steps (only visible in the modifier’s tab)
Handrail Material: Material Used for the Handrail (only visible in the modifier’s tab)
Baluster Material: Material Used for the Balusters (only visible in the modifier’s tab)
Column Material: Material Used for the Column (only visible in the modifier’s tab)
Reverse Direction: Reverse Staircase direction
Railing: Shows/Hides the Railing
Realize Instances: Activate this Only before applying the modifier to convert instances to mesh. (It may take some processing time)
Wood Color 1: Wood Color 1 (While using the default material)
Wood Color 2: Wood Color 2 (While using the default material)
Wood Finish: Wood Finish (While using the default material)
Handrail Number: Handrail number
Handrail Height: Handrail height from steps
Handrail Radius: Handrail radius
Stair Resolution: Stari Spiral Resolution
Stair Height: Stair Height (from first to last step)
Stair Turns: Total turns (from first to last step)
Steps per Turn: Amount of steps per turn (a stair with 2 turns and 20 steps per turn will have a total of 40 steps)
Remove 1st step: Removes the 1st step of the stair to avoid overlapping with the floor
Column Height: Column Height after last step
Column Radius: Column Radius
Step Width: Steps width
Step Depth: Steps Depth
Step Height: Steps Height
